Extended Length

Diameter

Click to view all

168mm

4/12

60mm

108mm

$36.00

GSA/G-168-108-0412

Buy Now

168mm

4/12

$36.00

GSA/G-168-108-0412

Buy Now

168mm Extended Length, 4/12 Diameter Gas Strut

$36.00

In Stock

Extended Length:

168mm

Diameter:

4/12

Stroke Length:

60mm

Compressed Length:

108mm

Force Range:

50-150N

Thread:

M4x0.7

End Fitting:

4mm Diameter Eyelet

Force Increase over stroke:

30%

Stroke Dampened:

15%

WHAT'S IN THE BOX::

4mm rod diameter (M4X0.7 THREAD UNDER JOINT) 12mm body diameter (M4X0.7 THREAD UNDER JOINT) 60mm stroke 30% force increase over stroke 15% stroke Dampened MAX 150N supplied with E44 4MM EYE

Product Code:

GSA/G-168-108-0412

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

178mm

4/12

60mm

118mm

$36.00

GSA/G-178-118-0412

Buy Now

178mm

4/12

$36.00

GSA/G-178-118-0412

Buy Now

178mm Extended Length, 4/12 Diameter Gas Strut

Out of stock

$36.00

Out Of Stock

Extended Length:

178mm

Diameter:

4/12

Stroke Length:

60mm

Compressed Length:

118mm

Force Range:

50-150N

Thread:

M4X0.7 THREAD

End Fitting:

4mm Diameter Eyelets

Force Increase over stroke:

30%

Stroke Dampened:

15%

WHAT'S IN THE BOX::

4mm rod diameter (M4X0.7 THREAD UNDER JOINT) 12mm body diameter (M4X0.7 THREAD UNDER JOINT) 66mm stroke 30% force increase over stroke 15% stroke Dampened MAX 150N supplied with E44 4MM EYE

Product Code:

GSA/G-178-118-0412

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

330mm

4/12

130mm

200mm

$36.00

GSA/G-330-200-0412

Buy Now

330mm

4/12

$36.00

GSA/G-330-200-0412

Buy Now

330mm Extended Length, 4/12 Diameter Gas Strut

$36.00

In Stock

Extended Length:

330mm

Diameter:

4/12

Stroke Length:

130mm

Compressed Length:

200mm

Force Range:

50-150N

Thread:

M4X0.7 Thread

End Fitting:

4mm Diameter Eyelets

Force Increase over stroke:

30%

Stroke Dampened:

15%

WHAT'S IN THE BOX::

4mm rod diameter (M4X0.7 THREAD UNDER JOINT) 12mm body diameter (M4X0.7 THREAD UNDER JOINT) 130mm stroke 30% force increase over stroke 15% stroke Dampened MAX 150N supplied with E44 4MM EYE

Product Code:

GSA/G-330-200-0412

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

220mm

6/15

75mm

145mm

$37.00

GSA/G-220-145-0615

Buy Now

220mm

6/15

$37.00

GSA/G-220-145-0615

Buy Now

220mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

220mm

Diameter:

6/15

Stroke Length:

75mm

Compressed Length:

145mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-220-145-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

380mm

6/15

155mm

225mm

$37.00

GSA/G-380-225-0615

Buy Now

380mm

6/15

$37.00

GSA/G-380-225-0615

Buy Now

380mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

380mm

Diameter:

6/15

Stroke Length:

155mm

Compressed Length:

225mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-380-225-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

230mm

6/15

80mm

150mm

$37.00

GSA/G-230-150-0615

Buy Now

230mm

6/15

$37.00

GSA/G-230-150-0615

Buy Now

230mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

230mm

Diameter:

6/15

Stroke Length:

80mm

Compressed Length:

150mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-230-150-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

410mm

6/15

170mm

240mm

$37.00

GSA/G-410-240-0615

Buy Now

410mm

6/15

$37.00

GSA/G-410-240-0615

Buy Now

410mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

410mm

Diameter:

6/15

Stroke Length:

170mm

Compressed Length:

240mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-410-240-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

240mm

6/15

85mm

155mm

$37.00

GSA/G-240-155-0615

Buy Now

240mm

6/15

$37.00

GSA/G-240-155-0615

Buy Now

240mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

240mm

Diameter:

6/15

Stroke Length:

85mm

Compressed Length:

155mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-240-155-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

430mm

6/15

180mm

250mm

$37.00

GSA/G-430-250-0615

Buy Now

430mm

6/15

$37.00

GSA/G-430-250-0615

Buy Now

430mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

430mm

Diameter:

6/15

Stroke Length:

180mm

Compressed Length:

250mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-430-250-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

250mm

6/15

90mm

160mm

$37.00

GSA/G-250-160-0615

Buy Now

250mm

6/15

$37.00

GSA/G-250-160-0615

Buy Now

250mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

250mm

Diameter:

6/15

Stroke Length:

90mm

Compressed Length:

160mm

Force Range:

50-400N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-250-160-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

500mm

6/15

215mm

285mm

$37.00

GSA/G-500-285-0615

Buy Now

500mm

6/15

$37.00

GSA/G-500-285-0615

Buy Now

500mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

500mm

Diameter:

6/15

Stroke Length:

215mm

Compressed Length:

285mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-500-285-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

280mm

6/15

105mm

175mm

$37.00

GSA/G-280-175-0615

Buy Now

280mm

6/15

$37.00

GSA/G-280-175-0615

Buy Now

280mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

280mm

Diameter:

6/15

Stroke Length:

105mm

Compressed Length:

175mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-280-175-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

300mm

6/15

115mm

185mm

$37.00

GSA/G-300-185-0615

Buy Now

300mm

6/15

$37.00

GSA/G-300-185-0615

Buy Now

300mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

300mm

Diameter:

6/15

Stroke Length:

115mm

Compressed Length:

185mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-300-185-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

142mm

6/15

35mm

107mm

$37.00

GSA/G-142-107-0615

Buy Now

142mm

6/15

$37.00

GSA/G-142-107-0615

Buy Now

142mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

142mm

Diameter:

6/15

Stroke Length:

35mm

Compressed Length:

107mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-142-107-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

315mm

6/15

125mm

190mm

$37.00

GSA/G-315-190-0615

Buy Now

315mm

6/15

$37.00

GSA/G-315-190-0615

Buy Now

315mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

315mm

Diameter:

6/15

Stroke Length:

125mm

Compressed Length:

190mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-315-190-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

177mm

6/15

54mm

87mm

$37.00

GSA/G-177-087-0615

Buy Now

177mm

6/15

$37.00

GSA/G-177-087-0615

Buy Now

177mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

177mm

Diameter:

6/15

Stroke Length:

54mm

Compressed Length:

87mm

Force Range:

50-400N

Thread:

M6X1.0 Thread

End Fitting:

GSA/F-BCP10-18BM6

Force Increase over stroke:

30%

Stroke Dampened:

15%

Product Code:

GSA/G-177-087-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

150mm

6/15

40mm

110mm

$37.00

GSA/G-150-110-0615

Buy Now

150mm

6/15

$37.00

GSA/G-150-110-0615

Buy Now

150mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

150mm

Diameter:

6/15

Stroke Length:

40mm

Compressed Length:

110mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-150-110-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

330mm

6/15

130mm

200mm

$37.00

GSA/G-330-200-0615

Buy Now

330mm

6/15

$37.00

GSA/G-330-200-0615

Buy Now

330mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

330mm

Diameter:

6/15

Stroke Length:

130mm

Compressed Length:

200mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-330-200-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

226mm

6/15

80mm

110mm

$37.00

GSA/G-226-110-0615

Buy Now

226mm

6/15

$37.00

GSA/G-226-110-0615

Buy Now

226mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

226mm

Diameter:

6/15

Stroke Length:

80mm

Compressed Length:

110mm

Force Range:

50-400N

Thread:

M6X1.0 Thread

End Fitting:

GSA/F-BCP10-18BM6

Force Increase over stroke:

30%

Stroke Dampened:

15%

Product Code:

GSA/G-226-110-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

165mm

6/15

45mm

120mm

$37.00

GSA/G-165-120-0615

Buy Now

165mm

6/15

$37.00

GSA/G-165-120-0615

Buy Now

165mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

165mm

Diameter:

6/15

Stroke Length:

45mm

Compressed Length:

120mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-165-120-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

340mm

6/15

135mm

205mm

$37.00

GSA/G-340-205-0615

Buy Now

340mm

6/15

$37.00

GSA/G-340-205-0615

Buy Now

340mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

340mm

Diameter:

6/15

Stroke Length:

135mm

Compressed Length:

205mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-340-205-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

495mm

6/15

214mm

243mm

$37.00

GSA/G-495-243-0615

Buy Now

495mm

6/15

$37.00

GSA/G-495-243-0615

Buy Now

495mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

495mm

Diameter:

6/15

Stroke Length:

214mm

Compressed Length:

243mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Force Increase over stroke:

30%

Stroke Dampened:

15%

Product Code:

GSA/G-495-243-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

180mm

6/15

55mm

125mm

$37.00

GSA/G-180-125-0615

Buy Now

180mm

6/15

$37.00

GSA/G-180-125-0615

Buy Now

180mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

180mm

Diameter:

6/15

Stroke Length:

55mm

Compressed Length:

125mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-180-125-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

355mm

6/15

145mm

210mm

$37.00

GSA/G-355-210-0615

Buy Now

355mm

6/15

$37.00

GSA/G-355-210-0615

Buy Now

355mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

355mm

Diameter:

6/15

Stroke Length:

145mm

Compressed Length:

210mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-355-210-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

145mm

6/15

40mm

105mm

$37.00

GSA/G-145-105-0615

Buy Now

145mm

6/15

$37.00

GSA/G-145-105-0615

Buy Now

145mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

145mm

Diameter:

6/15

Stroke Length:

40mm

Compressed Length:

105mm

Force Range:

50-400N

Thread:

M6x1.0

Special Note:

These gas struts come with 6mm Eyelet

End Fitting:

GSA/F-EM-1X4

WHAT'S IN THE BOX::

145mm Extended Length with 6mm Eyelets

Product Code:

GSA/G-145-105-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

195mm

6/15

60mm

135mm

$37.00

GSA/G-195-135-0615

Buy Now

195mm

6/15

$37.00

GSA/G-195-135-0615

Buy Now

195mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

195mm

Diameter:

6/15

Stroke Length:

60mm

Compressed Length:

135mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-195-135-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

375mm

6/15

155mm

220mm

$37.00

GSA/G-375-220-0615

Buy Now

375mm

6/15

$37.00

GSA/G-375-220-0615

Buy Now

375mm Extended Length, 6/15 Diameter Gas Strut

$37.00

In Stock

Extended Length:

375mm

Diameter:

6/15

Stroke Length:

155mm

Compressed Length:

220mm

Force Range:

50-400N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-375-220-0615

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

230mm

8/18

80mm

155mm

$45.00

GSA/G-230-155-0818

Buy Now

230mm

8/18

$45.00

GSA/G-230-155-0818

Buy Now

230mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

230mm

Diameter:

8/18

Stroke Length:

80mm

Compressed Length:

155mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-230-155-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

585mm

8/18

255mm

330mm

$45.00

GSA/G-585-330-0818

Buy Now

585mm

8/18

$45.00

GSA/G-585-330-0818

Buy Now

585mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

585mm

Diameter:

8/18

Stroke Length:

255mm

Compressed Length:

330mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-585-330-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

375mm

8/18

150mm

225mm

$45.00

GSA/G-375-225-0818

Buy Now

375mm

8/18

$45.00

GSA/G-375-225-0818

Buy Now

375mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

375mm

Diameter:

8/18

Stroke Length:

150mm

Compressed Length:

225mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-375-225-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

750mm

8/18

340mm

410mm

$45.00

GSA/G-750-410-0818

Buy Now

750mm

8/18

$45.00

GSA/G-750-410-0818

Buy Now

750mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

750mm

Diameter:

8/18

Stroke Length:

340mm

Compressed Length:

410mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-750-410-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

485mm

8/18

205mm

280mm

$45.00

GSA/G-485-280-0818

Buy Now

485mm

8/18

$45.00

GSA/G-485-280-0818

Buy Now

485mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

485mm

Diameter:

8/18

Stroke Length:

205mm

Compressed Length:

280mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-485-280-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

245mm

8/18

85mm

160mm

$45.00

GSA/G-245-160-0818

Buy Now

245mm

8/18

$45.00

GSA/G-245-160-0818

Buy Now

245mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

245mm

Diameter:

8/18

Stroke Length:

85mm

Compressed Length:

160mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-245-160-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

595mm

8/18

260mm

335mm

$45.00

GSA/G-595-335-0818

Buy Now

595mm

8/18

$45.00

GSA/G-595-335-0818

Buy Now

595mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

595mm

Diameter:

8/18

Stroke Length:

260mm

Compressed Length:

335mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-595-335-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

385mm

8/18

155mm

230mm

$45.00

GSA/G-385-230-0818

Buy Now

385mm

8/18

$45.00

GSA/G-385-230-0818

Buy Now

385mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

385mm

Diameter:

8/18

Stroke Length:

155mm

Compressed Length:

230mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-385-230-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

800mm

8/18

365mm

435mm

$45.00

GSA/G-800-435-0818

Buy Now

800mm

8/18

$45.00

GSA/G-800-435-0818

Buy Now

800mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

800mm

Diameter:

8/18

Stroke Length:

365mm

Compressed Length:

435mm

Force Range:

50-500N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-800-435-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

500mm

8/18

210mm

290mm

$45.00

GSA/G-500-290-0818

Buy Now

500mm

8/18

$45.00

GSA/G-500-290-0818

Buy Now

500mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

500mm

Diameter:

8/18

Stroke Length:

210mm

Compressed Length:

290mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-500-290-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

265mm

8/18

95mm

170mm

$45.00

GSA/G-265-170-0818

Buy Now

265mm

8/18

$45.00

GSA/G-265-170-0818

Buy Now

265mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

265mm

Diameter:

8/18

Stroke Length:

95mm

Compressed Length:

170mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-265-170-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

600mm

8/18

265mm

335mm

$45.00

GSA/G-600-335-0818

Buy Now

600mm

8/18

$45.00

GSA/G-600-335-0818

Buy Now

600mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

600mm

Diameter:

8/18

Stroke Length:

265mm

Compressed Length:

335mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-600-335-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

405mm

8/18

165mm

240mm

$45.00

GSA/G-405-240-0818

Buy Now

405mm

8/18

$45.00

GSA/G-405-240-0818

Buy Now

405mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

405mm

Diameter:

8/18

Stroke Length:

165mm

Compressed Length:

240mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCM10-18BM6

Product Code:

GSA/G-405-240-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

505mm

8/18

215mm

290mm

$45.00

GSA/G-505-290-0818

Buy Now

505mm

8/18

$45.00

GSA/G-505-290-0818

Buy Now

505mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

505mm

Diameter:

8/18

Stroke Length:

215mm

Compressed Length:

290mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-505-290-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

275mm

8/18

100mm

175mm

$45.00

GSA/G-275-175-0818

Buy Now

275mm

8/18

$45.00

GSA/G-275-175-0818

Buy Now

275mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

275mm

Diameter:

8/18

Stroke Length:

100mm

Compressed Length:

175mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-275-175-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

615mm

8/18

270mm

345mm

$45.00

GSA/G-615-345-0818

Buy Now

615mm

8/18

$45.00

GSA/G-615-345-0818

Buy Now

615mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

615mm

Diameter:

8/18

Stroke Length:

270mm

Compressed Length:

345mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-615-345-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

410mm

8/18

165mm

245mm

$45.00

GSA/G-410-245-0818

Buy Now

410mm

8/18

$45.00

GSA/G-410-245-0818

Buy Now

410mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

410mm

Diameter:

8/18

Stroke Length:

165mm

Compressed Length:

245mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCM10-18BM6

Product Code:

GSA/G-410-245-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

510mm

8/18

215mm

295mm

$45.00

GSA/G-510-295-0818

Buy Now

510mm

8/18

$45.00

GSA/G-510-295-0818

Buy Now

510mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

510mm

Diameter:

8/18

Stroke Length:

215mm

Compressed Length:

295mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-510-295-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

290mm

8/18

110mm

180mm

$45.00

GSA/G-290-180-0818

Buy Now

290mm

8/18

$45.00

GSA/G-290-180-0818

Buy Now

290mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

290mm

Diameter:

8/18

Stroke Length:

110mm

Compressed Length:

180mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-290-180-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

630mm

8/18

275mm

355mm

$45.00

GSA/G-630-355-0818

Buy Now

630mm

8/18

$45.00

GSA/G-630-355-0818

Buy Now

630mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

630mm

Diameter:

8/18

Stroke Length:

275mm

Compressed Length:

355mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-630-355-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

415mm

8/18

170mm

245mm

$45.00

GSA/G-415-245-0818

Buy Now

415mm

8/18

$45.00

GSA/G-415-245-0818

Buy Now

415mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

415mm

Diameter:

8/18

Stroke Length:

170mm

Compressed Length:

245mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-415-245-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

175mm

8/18

50mm

125mm

$45.00

GSA/G-175-125-0818

Buy Now

175mm

8/18

$45.00

GSA/G-175-125-0818

Buy Now

175mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

175mm

Diameter:

8/18

Stroke Length:

50mm

Compressed Length:

125mm

Force Range:

50-700N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-175-125-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

525mm

8/18

225mm

300mm

$45.00

GSA/G-525-300-0818

Buy Now

525mm

8/18

$45.00

GSA/G-525-300-0818

Buy Now

525mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

525mm

Diameter:

8/18

Stroke Length:

225mm

Compressed Length:

300mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-525-300-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

330mm

8/18

125mm

205mm

$45.00

GSA/G-330-205-0818

Buy Now

330mm

8/18

$45.00

GSA/G-330-205-0818

Buy Now

330mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

330mm

Diameter:

8/18

Stroke Length:

125mm

Compressed Length:

205mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-330-205-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

305mm

8/18

115mm

190mm

$45.00

GSA/G-305-190-0818

Buy Now

305mm

8/18

$45.00

GSA/G-305-190-0818

Buy Now

305mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

305mm

Diameter:

8/18

Stroke Length:

115mm

Compressed Length:

190mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BC910-18M6

Product Code:

GSA/G-305-190-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

650mm

8/18

285mm

365mm

$45.00

GSA/G-650-365-0818

Buy Now

650mm

8/18

$45.00

GSA/G-650-365-0818

Buy Now

650mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

650mm

Diameter:

8/18

Stroke Length:

285mm

Compressed Length:

365mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-650-365-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

425mm

8/18

175mm

250mm

$45.00

GSA/G-425-250-0818

Buy Now

425mm

8/18

$45.00

GSA/G-425-250-0818

Buy Now

425mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

425mm

Diameter:

8/18

Stroke Length:

175mm

Compressed Length:

250mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-425-250-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

195mm

8/18

57mm

138mm

$45.00

GSA/G-195-138-0818

Buy Now

195mm

8/18

$45.00

GSA/G-195-138-0818

Buy Now

195mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

195mm

Diameter:

8/18

Stroke Length:

57mm

Compressed Length:

138mm

Force Range:

50-700N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-195-138-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

535mm

8/18

230mm

305mm

$45.00

GSA/G-535-305-0818

Buy Now

535mm

8/18

$45.00

GSA/G-535-305-0818

Buy Now

535mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

535mm

Diameter:

8/18

Stroke Length:

230mm

Compressed Length:

305mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

WHAT'S IN THE BOX::

10mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-535-305-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

250mm

8/18

85mm

160mm

$45.00

GSA/G-250-160-0818

Buy Now

250mm

8/18

$45.00

GSA/G-250-160-0818

Buy Now

250mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

250mm

Diameter:

8/18

Stroke Length:

85mm

Compressed Length:

160mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-250-160-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

320mm

8/18

120mm

200mm

$45.00

GSA/G-320-200-0818

Buy Now

320mm

8/18

$45.00

GSA/G-320-200-0818

Buy Now

320mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

320mm

Diameter:

8/18

Stroke Length:

120mm

Compressed Length:

200mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-320-200-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

670mm

8/18

295mm

375mm

$45.00

GSA/G-670-375-0818

Buy Now

670mm

8/18

$45.00

GSA/G-670-375-0818

Buy Now

670mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

670mm

Diameter:

8/18

Stroke Length:

295mm

Compressed Length:

375mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-670-375-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

430mm

8/18

180mm

250mm

$45.00

GSA/G-430-250-0818

Buy Now

430mm

8/18

$45.00

GSA/G-430-250-0818

Buy Now

430mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

430mm

Diameter:

8/18

Stroke Length:

180mm

Compressed Length:

250mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-430-250-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

220mm

8/18

70mm

150mm

$45.00

GSA/G-220-150-0818

Buy Now

220mm

8/18

$45.00

GSA/G-220-150-0818

Buy Now

220mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

220mm

Diameter:

8/18

Stroke Length:

70mm

Compressed Length:

150mm

Force Range:

50-700N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-220-150-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

540mm

8/18

235mm

305mm

$45.00

GSA/G-540-305-0818

Buy Now

540mm

8/18

$45.00

GSA/G-540-305-0818

Buy Now

540mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

540mm

Diameter:

8/18

Stroke Length:

235mm

Compressed Length:

305mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-540-305-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

285mm

8/18

105mm

180mm

$45.00

GSA/G-285-180-0818

Buy Now

285mm

8/18

$45.00

GSA/G-285-180-0818

Buy Now

285mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

285mm

Diameter:

8/18

Stroke Length:

105mm

Compressed Length:

180mm

Force Range:

50-700N

Thread:

M6X1.0

End Fitting:

GSA/F-BCP10-18BM6

WHAT'S IN THE BOX::

1 x Gas Strut, 2 x 10mm Plastic Ball Cups with M6 Thread, 2 x 10mm Ball Stud with M8 Thread

Product Code:

GSA/G-285-180-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

336mm

8/18

130mm

206mm

$45.00

GSA/G-336-206-0818

Buy Now

336mm

8/18

$45.00

GSA/G-336-206-0818

Buy Now

336mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

336mm

Diameter:

8/18

Stroke Length:

130mm

Compressed Length:

206mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-336-206-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

680mm

8/18

305mm

385mm

$45.00

GSA/G-680-385-0818

Buy Now

680mm

8/18

$45.00

GSA/G-680-385-0818

Buy Now

680mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

680mm

Diameter:

8/18

Stroke Length:

305mm

Compressed Length:

385mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-680-385-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

450mm

8/18

185mm

265mm

$45.00

GSA/G-450-265-0818

Buy Now

450mm

8/18

$45.00

GSA/G-450-265-0818

Buy Now

450mm Extended Length, 8/18 diameter Gas Strut

$45.00

In Stock

Extended Length:

450mm

Diameter:

8/18

Stroke Length:

185mm

Compressed Length:

265mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-450-265-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

550mm

8/18

240mm

310mm

$45.00

GSA/G-550-310-0818

Buy Now

550mm

8/18

$45.00

GSA/G-550-310-0818

Buy Now

550mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

550mm

Diameter:

8/18

Stroke Length:

240mm

Compressed Length:

310mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-550-310-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

315mm

8/18

120mm

195mm

$45.00

GSA/G-315-195-0818

Buy Now

315mm

8/18

$45.00

GSA/G-315-195-0818

Buy Now

315mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

315mm

Diameter:

8/18

Stroke Length:

120mm

Compressed Length:

195mm

Force Range:

50-700N

Thread:

M6X1.0

Special Note:

The Extended Length is measured from centre of hole to centre of hole. The Extended Length includes End Fittings. 8/18mm Diameter = 18mm Length End Fittings

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-315-195-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

340mm

8/18

135mm

205mm

$45.00

GSA/G-340-205-0818

Buy Now

340mm

8/18

$45.00

GSA/G-340-205-0818

Buy Now

340mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

340mm

Diameter:

8/18

Stroke Length:

135mm

Compressed Length:

205mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-340-205-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

700mm

8/18

315mm

385mm

$45.00

GSA/G-700-385-0818

Buy Now

700mm

8/18

$45.00

GSA/G-700-385-0818

Buy Now

700mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

700mm

Diameter:

8/18

Stroke Length:

315mm

Compressed Length:

385mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-700-385-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

460mm

8/18

190mm

270mm

$45.00

GSA/G-460-270-0818

Buy Now

460mm

8/18

$45.00

GSA/G-460-270-0818

Buy Now

460mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

460mm

Diameter:

8/18

Stroke Length:

190mm

Compressed Length:

270mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-460-270-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

565mm

8/18

245mm

320mm

$45.00

GSA/G-565-320-0818

Buy Now

565mm

8/18

$45.00

GSA/G-565-320-0818

Buy Now

565mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

565mm

Diameter:

8/18

Stroke Length:

245mm

Compressed Length:

320mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-565-320-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

520mm

8/18

225mm

295mm

$45.00

GSA/G-520-295-0818

Buy Now

520mm

8/18

$45.00

GSA/G-520-295-0818

Buy Now

520mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

520mm

Diameter:

8/18

Stroke Length:

225mm

Compressed Length:

295mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

10mm Diameter Plastic Ball Cups & 10mm Diameter Ball Studs

Product Code:

GSA/G-520-295-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

350mm

8/18

135mm

215mm

$45.00

GSA/G-350-215-0818

Buy Now

350mm

8/18

$45.00

GSA/G-350-215-0818

Buy Now

350mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

350mm

Diameter:

8/18

Stroke Length:

135mm

Compressed Length:

215mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-350-215-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

720mm

8/18

325mm

395mm

$45.00

GSA/G-720-325-0818

Buy Now

720mm

8/18

$45.00

GSA/G-720-325-0818

Buy Now

720mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

720mm

Diameter:

8/18

Stroke Length:

325mm

Compressed Length:

395mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-720-325-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

465mm

8/18

195mm

270mm

$45.00

GSA/G-465-270-0818

Buy Now

465mm

8/18

$45.00

GSA/G-465-270-0818

Buy Now

465mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

465mm

Diameter:

8/18

Stroke Length:

195mm

Compressed Length:

270mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-465-270-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

575mm

8/18

250mm

325mm

$45.00

GSA/G-575-325-0818

Buy Now

575mm

8/18

$45.00

GSA/G-575-325-0818

Buy Now

575mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

575mm

Diameter:

8/18

Stroke Length:

250mm

Compressed Length:

325mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-575-325-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

365mm

8/18

145mm

220mm

$45.00

GSA/G-365-220-0818

Buy Now

365mm

8/18

$45.00

GSA/G-365-220-0818

Buy Now

365mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

365mm

Diameter:

8/18

Stroke Length:

145mm

Compressed Length:

220mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-365-220-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

730mm

8/18

330mm

400mm

$45.00

GSA/G-730-400-0818

Buy Now

730mm

8/18

$45.00

GSA/G-730-400-0818

Buy Now

730mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

730mm

Diameter:

8/18

Stroke Length:

330mm

Compressed Length:

400mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-730-400-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

470mm

8/18

195mm

275mm

$45.00

GSA/G-470-275-0818

Buy Now

470mm

8/18

$45.00

GSA/G-470-275-0818

Buy Now

470mm Extended Length, 8/18 Diameter Gas Strut

$45.00

In Stock

Extended Length:

470mm

Diameter:

8/18

Stroke Length:

195mm

Compressed Length:

275mm

Force Range:

50-700N

Thread:

M6x1.0

End Fitting:

GSA/F-BCP10-18BM6

Product Code:

GSA/G-470-275-0818

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

940mm

10/22

430mm

510mm

$65.75

GSA/G-940-510-1022

Buy Now

940mm

10/22

$65.75

GSA/G-940-510-1022

Buy Now

940mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

940mm

Diameter:

10/22

Stroke Length:

430mm

Compressed Length:

510mm

Force Range:

50-1000N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-940-510-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

800mm

10/22

360mm

440mm

$65.75

GSA/G-800-440-1022

Buy Now

800mm

10/22

$65.75

GSA/G-800-440-1022

Buy Now

800mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

800mm

Diameter:

10/22

Stroke Length:

360mm

Compressed Length:

440mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM10

Product Code:

GSA/G-800-440-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

470mm

10/22

193mm

277mm

$65.75

GSA/G-470-277-1022

Buy Now

470mm

10/22

$65.75

GSA/G-470-277-1022

Buy Now

470mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

470mm

Diameter:

10/22

Stroke Length:

193mm

Compressed Length:

277mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

Product Code:

GSA/G-470-277-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

700mm

10/22

310mm

390mm

$65.75

GSA/G-700-390-1022

Buy Now

700mm

10/22

$65.75

GSA/G-700-390-1022

Buy Now

700mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

700mm

Diameter:

10/22

Stroke Length:

310mm

Compressed Length:

390mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-700-390-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

975mm

10/22

445mm

530mm

$65.75

GSA/G-975-530-1022

Buy Now

975mm

10/22

$65.75

GSA/G-975-530-1022

Buy Now

975mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

975mm

Diameter:

10/22

Stroke Length:

445mm

Compressed Length:

530mm

Force Range:

50-1000N

Thread:

M8X1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-975-530-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

530mm

10/22

220mm

310mm

$65.75

GSA/G-530-270-1022

Buy Now

530mm

10/22

$65.75

GSA/G-530-270-1022

Buy Now

530mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

530mm

Diameter:

10/22

Stroke Length:

220mm

Compressed Length:

310mm

Force Range:

50-1200N

Thread:

M8x1.25

Special Note:

30% force increase over stroke, 15% stroke Dampened

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-530-270-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

485mm

10/22

200mm

285mm

$65.75

GSA/G-485-285-1022

Buy Now

485mm

10/22

$65.75

GSA/G-485-285-1022

Buy Now

485mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

485mm

Diameter:

10/22

Stroke Length:

200mm

Compressed Length:

285mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

Product Code:

GSA/G-485-285-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

730mm

10/22

325mm

405mm

$65.75

GSA/G-730-405-1022

Buy Now

730mm

10/22

$65.75

GSA/G-730-405-1022

Buy Now

730mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

730mm

Diameter:

10/22

Stroke Length:

325mm

Compressed Length:

405mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-730-405-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

1035mm

10/22

470mm

565mm

$65.75

GSA/G-1035-565-1022

Buy Now

1035mm

10/22

$65.75

GSA/G-1035-565-1022

Buy Now

1035mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

1035mm

Diameter:

10/22

Stroke Length:

470mm

Compressed Length:

565mm

Force Range:

50-1000N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-1035-565-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

195mm

10/22

60mm

135mm

$65.75

GSA/G-195-135-1022

Buy Now

195mm

10/22

$65.75

GSA/G-195-135-1022

Buy Now

195mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

195mm

Diameter:

10/22

Stroke Length:

60mm

Compressed Length:

135mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

Product Code:

GSA/G-195-135-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

500mm

10/22

210mm

290mm

$65.75

GSA/G-500-290-1022

Buy Now

500mm

10/22

$65.75

GSA/G-500-290-1022

Buy Now

500mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

500mm

Diameter:

10/22

Stroke Length:

210mm

Compressed Length:

290mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

Product Code:

GSA/G-500-290-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

750mm

10/22

335mm

415mm

$65.75

GSA/G-750-415-1022

Buy Now

750mm

10/22

$65.75

GSA/G-750-415-1022

Buy Now

750mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

750mm

Diameter:

10/22

Stroke Length:

335mm

Compressed Length:

415mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-750-415-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

1100mm

10/22

505mm

595mm

$80.95

GSA/G-1100-595-1022

Buy Now

1100mm

10/22

$80.95

GSA/G-1100-595-1022

Buy Now

1100mm Extended Length, 10/22 Diameter Gas Strut

$80.95

In Stock

Extended Length:

1100mm

Diameter:

10/22

Stroke Length:

505mm

Compressed Length:

595mm

Force Range:

50-1000N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-1100-595-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

250mm

10/22

85mm

165mm

$65.75

GSA/G-250-165-1022

Buy Now

250mm

10/22

$65.75

GSA/G-250-165-1022

Buy Now

250mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

250mm

Diameter:

10/22

Stroke Length:

85mm

Compressed Length:

165mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

Product Code:

GSA/G-250-165-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

505mm

10/22

210mm

295mm

$65.75

GSA/G-505-295-1022

Buy Now

505mm

10/22

$65.75

GSA/G-505-295-1022

Buy Now

505mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

505mm

Diameter:

10/22

Stroke Length:

210mm

Compressed Length:

295mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

Product Code:

GSA/G-505-295-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

770mm

10/22

345mm

425mm

$65.75

GSA/G-770-425-1022

Buy Now

770mm

10/22

$65.75

GSA/G-770-425-1022

Buy Now

770mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

770mm

Diameter:

10/22

Stroke Length:

345mm

Compressed Length:

425mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-770-425-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

1200mm

10/22

555mm

645mm

$80.95

GSA/G-1200-645-1022

Buy Now

1200mm

10/22

$80.95

GSA/G-1200-645-1022

Buy Now

1200mm Extended Length, 10/22 Diameter Gas Strut

$80.95

In Stock

Extended Length:

1200mm

Diameter:

10/22

Stroke Length:

555mm

Compressed Length:

645mm

Force Range:

50-1000N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-1200-645-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

295mm

10/22

105mm

190mm

$65.75

GSA/G-295-190-1022

Buy Now

295mm

10/22

$65.75

GSA/G-295-190-1022

Buy Now

295mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

295mm

Diameter:

10/22

Stroke Length:

105mm

Compressed Length:

190mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

Product Code:

GSA/G-295-190-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

550mm

10/22

235mm

315mm

$65.75

GSA/G-550-315-1022

Buy Now

550mm

10/22

$65.75

GSA/G-550-315-1022

Buy Now

550mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

550mm

Diameter:

10/22

Stroke Length:

235mm

Compressed Length:

315mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCP13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-550-315-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

525mm

10/22

225mm

305mm

$65.75

GSA/G-525-305-1022

Buy Now

525mm

10/22

$65.75

GSA/G-525-305-1022

Buy Now

525mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

525mm

Diameter:

10/22

Stroke Length:

225mm

Compressed Length:

305mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-525-305-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

795mm

10/22

355mm

440mm

$65.75

GSA/G-795-440-1022

Buy Now

795mm

10/22

$65.75

GSA/G-795-440-1022

Buy Now

795mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

795mm

Diameter:

10/22

Stroke Length:

355mm

Compressed Length:

440mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-795-440-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

330mm

10/22

125mm

205mm

$65.75

GSA/G-330-205-1022

Buy Now

330mm

10/22

$65.75

GSA/G-330-205-1022

Buy Now

330mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

330mm

Diameter:

10/22

Stroke Length:

125mm

Compressed Length:

205mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

Product Code:

GSA/G-330-205-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

565mm

10/22

240mm

325mm

$65.75

GSA/G-565-325-1022

Buy Now

565mm

10/22

$65.75

GSA/G-565-325-1022

Buy Now

565mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

565mm

Diameter:

10/22

Stroke Length:

240mm

Compressed Length:

325mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM10-21EM8

Product Code:

GSA/G-565-325-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

816mm

10/22

365mm

451mm

$65.75

GSA/G-816-451-1022

Buy Now

816mm

10/22

$65.75

GSA/G-816-451-1022

Buy Now

816mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

816mm

Diameter:

10/22

Stroke Length:

365mm

Compressed Length:

451mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-816-451-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

350mm

10/22

135mm

215mm

$65.75

GSA/G-350-215-1022

Buy Now

350mm

10/22

$65.75

GSA/G-350-215-1022

Buy Now

350mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

350mm

Diameter:

10/22

Stroke Length:

135mm

Compressed Length:

215mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

Product Code:

GSA/G-350-215-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

595mm

10/22

255mm

340mm

$65.75

GSA/G-595-340-1022

Buy Now

595mm

10/22

$65.75

GSA/G-595-340-1022

Buy Now

595mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

595mm

Diameter:

10/22

Stroke Length:

255mm

Compressed Length:

340mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-595-340-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

830mm

10/22

375mm

455mm

$65.75

GSA/G-830-455-1022

Buy Now

830mm

10/22

$65.75

GSA/G-830-455-1022

Buy Now

830mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

830mm

Diameter:

10/22

Stroke Length:

375mm

Compressed Length:

455mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-830-455-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

375mm

10/22

145mm

230mm

$65.75

GSA/G-375-230-1022

Buy Now

375mm

10/22

$65.75

GSA/G-375-230-1022

Buy Now

375mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

375mm

Diameter:

10/22

Stroke Length:

145mm

Compressed Length:

230mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

Product Code:

GSA/G-375-230-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

620mm

10/22

270mm

350mm

$65.75

GSA/G-620-350-1022

Buy Now

620mm

10/22

$65.75

GSA/G-620-350-1022

Buy Now

620mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

620mm

Diameter:

10/22

Stroke Length:

270mm

Compressed Length:

350mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-620-350-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

850mm

10/22

380mm

470mm

$65.75

GSA/G-850-470-1022

Buy Now

850mm

10/22

$65.75

GSA/G-850-470-1022

Buy Now

850mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

850mm

Diameter:

10/22

Stroke Length:

380mm

Compressed Length:

470mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-850-470-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

405mm

10/22

160mm

245mm

$65.75

GSA/G-405-245-1022

Buy Now

405mm

10/22

$65.75

GSA/G-405-245-1022

Buy Now

405mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

405mm

Diameter:

10/22

Stroke Length:

160mm

Compressed Length:

245mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

Product Code:

GSA/G-405-245-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

630mm

10/22

275mm

355mm

$65.75

GSA/G-630-355-1022

Buy Now

630mm

10/22

$65.75

GSA/G-630-355-1022

Buy Now

630mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

630mm

Diameter:

10/22

Stroke Length:

275mm

Compressed Length:

355mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM10-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-630-355-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

900mm

10/22

405mm

495mm

$65.75

GSA/G-900-495-1022

Buy Now

900mm

10/22

$65.75

GSA/G-900-495-1022

Buy Now

900mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

900mm

Diameter:

10/22

Stroke Length:

405mm

Compressed Length:

495mm

Force Range:

50-1000N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-900-495-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

1000mm

10/22

355mm

645mm

$110.00

GSA/G-1000-645-1022

Buy Now

1000mm

10/22

$110.00

GSA/G-1000-645-1022

Buy Now

1000mm Extended Length, 10/22 Diameter Gas Strut

$110.00

In Stock

Extended Length:

1000mm

Diameter:

10/22

Stroke Length:

355mm

Compressed Length:

645mm

Force Range:

50-600N

Thread:

M8x1.25

End Fitting:

13mm Metal Ball Cups

Force Increase over stroke:

30%

Stroke Dampened:

15%

WHAT'S IN THE BOX::

1000mm Extended Length Strut with 13mm Ball Cups & 13mm Ball Studs with M8 Thread

Product Code:

GSA/G-1000-645-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

430mm

10/22

175mm

255mm

$65.75

GSA/G-430-255-1022

Buy Now

430mm

10/22

$65.75

GSA/G-430-255-1022

Buy Now

430mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

430mm

Diameter:

10/22

Stroke Length:

175mm

Compressed Length:

255mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

Product Code:

GSA/G-430-255-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

650mm

10/22

285mm

365mm

$65.75

GSA/G-650-365-1022

Buy Now

650mm

10/22

$65.75

GSA/G-650-365-1022

Buy Now

650mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

650mm

Diameter:

10/22

Stroke Length:

285mm

Compressed Length:

365mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM10-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-650-365-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

930mm

10/22

420mm

510mm

$65.75

GSA/G-930-510-1022

Buy Now

930mm

10/22

$65.75

GSA/G-930-510-1022

Buy Now

930mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

930mm

Diameter:

10/22

Stroke Length:

420mm

Compressed Length:

510mm

Force Range:

50-1000N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-930-510-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

575mm

10/22

245mm

330mm

$65.75

GSA/G-575-330-1022

Buy Now

575mm

10/22

$65.75

GSA/G-575-330-1022

Buy Now

575mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

575mm

Diameter:

10/22

Stroke Length:

245mm

Compressed Length:

330mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-575-330-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

450mm

10/22

185mm

265mm

$65.75

GSA/G-450-265-1022

Buy Now

450mm

10/22

$65.75

GSA/G-450-265-1022

Buy Now

450mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

450mm

Diameter:

10/22

Stroke Length:

185mm

Compressed Length:

265mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

Product Code:

GSA/G-450-265-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

670mm

10/22

295mm

375mm

$65.75

GSA/G-670-375-1022

Buy Now

670mm

10/22

$65.75

GSA/G-670-375-1022

Buy Now

670mm Extended Length, 10/22 Diameter Gas Strut

$65.75

In Stock

Extended Length:

670mm

Diameter:

10/22

Stroke Length:

295mm

Compressed Length:

375mm

Force Range:

50-1200N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

13mm Diameter Metal Ball Cup & Ball Studs

Product Code:

GSA/G-670-375-1022

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

640mm

14/28

280mm

360mm

$78.95

GSA/G-640-360-1428

Buy Now

640mm

14/28

$78.95

GSA/G-640-360-1428

Buy Now

640mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

640mm

Diameter:

14/28

Stroke Length:

280mm

Compressed Length:

360mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21M10

Product Code:

GSA/G-640-360-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

900mm

14/28

405mm

495mm

$89.95

GSA/G-900-495-1428

Buy Now

900mm

14/28

$89.95

GSA/G-900-495-1428

Buy Now

900mm Extended Length, 14/28 Diameter Gas Strut

$89.95

In Stock

Extended Length:

900mm

Diameter:

14/28

Stroke Length:

405mm

Compressed Length:

495mm

Force Range:

50-2000N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21EM10

Product Code:

GSA/G-900-495-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

1000mm

14/28

355mm

650mm

$135.00

GSA/G-1000-610-350-1428

Buy Now

1000mm

14/28

$135.00

GSA/G-1000-610-350-1428

Buy Now

General Gas Strut 1000mm Extended Length, 14/28 Diameter Complete with 13mm Ball Cup End Fittings

$135.00

In Stock

Extended Length:

1000mm

Diameter:

14/28

Stroke Length:

355mm

Compressed Length:

650mm

Force Range:

-2500N

Thread:

M10X1.5

Special Note:

Reliable steel gas strut with B2SDS ends. Built for toolboxes, hatches, and access panels. Usually ships within 2 days. 3-year warranty guaranteed.

End Fitting:

B2SDS 13MM METAL JOINT WITH M10X1.5 THREAD 13MM BALL STUD

Force Increase over stroke:

22%

Stroke Dampened:

15%

WHAT'S IN THE BOX::

If using on rooftop tent please check compressed length to ensure it fits.

Product Code:

GSA/G-1000-610-350-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

375mm

14/28

145mm

230mm

$78.95

GSA/G-375-230-1428

Buy Now

375mm

14/28

$78.95

GSA/G-375-230-1428

Buy Now

375mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

375mm

Diameter:

14/28

Stroke Length:

145mm

Compressed Length:

230mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21M10

Product Code:

GSA/G-375-230-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

650mm

14/28

285mm

365mm

$78.95

GSA/G-650-365-1428

Buy Now

650mm

14/28

$78.95

GSA/G-650-365-1428

Buy Now

650mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

650mm

Diameter:

14/28

Stroke Length:

285mm

Compressed Length:

365mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21M10

Product Code:

GSA/G-650-365-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

940mm

14/28

425mm

515mm

$89.95

GSA/G-940-515-1428

Buy Now

940mm

14/28

$89.95

GSA/G-940-515-1428

Buy Now

940mm Extended Length, 14/28 Diameter Gas Strut

$89.95

In Stock

Extended Length:

940mm

Diameter:

14/28

Stroke Length:

425mm

Compressed Length:

515mm

Force Range:

50-2000N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21EM10

Product Code:

GSA/G-940-515-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

405mm

14/28

160mm

245mm

$78.95

GSA/G-405-245-1428

Buy Now

405mm

14/28

$78.95

GSA/G-405-245-1428

Buy Now

405mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

405mm

Diameter:

14/28

Stroke Length:

160mm

Compressed Length:

245mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21M10

Product Code:

GSA/G-405-245-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

670mm

14/28

295mm

375mm

$78.95

GSA/G-670-375-1428

Buy Now

670mm

14/28

$78.95

GSA/G-670-375-1428

Buy Now

670mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

670mm

Diameter:

14/28

Stroke Length:

295mm

Compressed Length:

375mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21EM10

Product Code:

GSA/G-670-375-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

690mm

14/28

290mm

400mm

$78.95

GSA/G-690-290-1428

Buy Now

690mm

14/28

$78.95

GSA/G-690-290-1428

Buy Now

690mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

690mm

Diameter:

14/28

Stroke Length:

290mm

Compressed Length:

400mm

Force Range:

50-2500N

Thread:

M8x1.25

End Fitting:

GSA/F-BCM13-21EM8

WHAT'S IN THE BOX::

690mm Extended Length Gas Strut 13MM METAL JOINT WITH M8x1.25 THREAD 13MM BALL STUD

Product Code:

GSA/G-690-290-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

1100mm

14/28

505mm

595mm

$89.95

GSA/G-1100-595-1428

Buy Now

1100mm

14/28

$89.95

GSA/G-1100-595-1428

Buy Now

1100mm Extended Length, 14/28 Diameter Gas Strut

$89.95

In Stock

Extended Length:

1100mm

Diameter:

14/28

Stroke Length:

505mm

Compressed Length:

595mm

Force Range:

50-1800N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21EM10

Product Code:

GSA/G-1100-595-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

430mm

14/28

175mm

255mm

$78.95

GSA/G-430-255-1428

Buy Now

430mm

14/28

$78.95

GSA/G-430-255-1428

Buy Now

430mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

430mm

Diameter:

14/28

Stroke Length:

175mm

Compressed Length:

255mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21M10

Product Code:

GSA/G-430-255-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

700mm

14/28

310mm

390mm

$78.95

GSA/G-700-390-1428

Buy Now

700mm

14/28

$78.95

GSA/G-700-390-1428

Buy Now

700mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

700mm

Diameter:

14/28

Stroke Length:

310mm

Compressed Length:

390mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21EM10

Product Code:

GSA/G-700-390-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

1200mm

14/28

555mm

645mm

$89.95

GSA/G-1200-645-1428

Buy Now

1200mm

14/28

$89.95

GSA/G-1200-645-1428

Buy Now

1200mm Extended Length, 14/28 Diameter Gas Strut

$89.95

In Stock

Extended Length:

1200mm

Diameter:

14/28

Stroke Length:

555mm

Compressed Length:

645mm

Force Range:

50-1800N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21EM10

Product Code:

GSA/G-1200-645-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

450mm

14/28

185mm

265mm

$78.95

GSA/G-450-265-1428

Buy Now

450mm

14/28

$78.95

GSA/G-450-265-1428

Buy Now

450mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

450mm

Diameter:

14/28

Stroke Length:

185mm

Compressed Length:

265mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21M10

Product Code:

GSA/G-450-265-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

720mm

14/28

320mm

400mm

$78.95

GSA/G-720-400-1428

Buy Now

720mm

14/28

$78.95

GSA/G-720-400-1428

Buy Now

720mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

720mm

Diameter:

14/28

Stroke Length:

320mm

Compressed Length:

400mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21EM10

Product Code:

GSA/G-720-400-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

485mm

14/28

200mm

285mm

$78.95

GSA/G-485-285-1428

Buy Now

485mm

14/28

$78.95

GSA/G-485-285-1428

Buy Now

485mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

485mm

Diameter:

14/28

Stroke Length:

200mm

Compressed Length:

285mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21M10

Product Code:

GSA/G-485-285-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

730mm

14/28

325mm

405mm

$78.95

GSA/G-730-405-1428

Buy Now

730mm

14/28

$78.95

GSA/G-730-405-1428

Buy Now

730mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

730mm

Diameter:

14/28

Stroke Length:

325mm

Compressed Length:

405mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21M10

Product Code:

GSA/G-730-405-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

505mm

14/28

210mm

295mm

$78.95

GSA/G-505-295-1428

Buy Now

505mm

14/28

$78.95

GSA/G-505-295-1428

Buy Now

505mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

505mm

Diameter:

14/28

Stroke Length:

210mm

Compressed Length:

295mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21M10

Product Code:

GSA/G-505-295-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

750mm

14/28

335mm

415mm

$78.95

GSA/G-750-415-1428

Buy Now

750mm

14/28

$78.95

GSA/G-750-415-1428

Buy Now

750mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

750mm

Diameter:

14/28

Stroke Length:

335mm

Compressed Length:

415mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21EM10

Product Code:

GSA/G-750-415-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

525mm

14/28

202mm

305mm

$78.95

GSA/G-525-305-1428

Buy Now

525mm

14/28

$78.95

GSA/G-525-305-1428

Buy Now

525mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

525mm

Diameter:

14/28

Stroke Length:

202mm

Compressed Length:

305mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21M10

Product Code:

GSA/G-525-305-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

800mm

14/28

360mm

440mm

$78.95

GSA/G-800-440-1428

Buy Now

800mm

14/28

$78.95

GSA/G-800-440-1428

Buy Now

800mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

800mm

Diameter:

14/28

Stroke Length:

360mm

Compressed Length:

440mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21EM10

Product Code:

GSA/G-800-440-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

195mm

14/28

60mm

135mm

$78.95

GSA/G-195-135-1428

Buy Now

195mm

14/28

$78.95

GSA/G-195-135-1428

Buy Now

195mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

195mm

Diameter:

14/28

Stroke Length:

60mm

Compressed Length:

135mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21M10

Product Code:

GSA/G-195-135-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

550mm

14/28

235mm

315mm

$78.95

GSA/G-550-315-1428

Buy Now

550mm

14/28

$78.95

GSA/G-550-315-1428

Buy Now

550mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

550mm

Diameter:

14/28

Stroke Length:

235mm

Compressed Length:

315mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21M10

Product Code:

GSA/G-550-315-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

830mm

14/28

375mm

455mm

$89.95

GSA/G-830-455-1428

Buy Now

830mm

14/28

$89.95

GSA/G-830-455-1428

Buy Now

830mm Extended Length, 14/28 Diameter Gas Strut

$89.95

In Stock

Extended Length:

830mm

Diameter:

14/28

Stroke Length:

375mm

Compressed Length:

455mm

Force Range:

50-2000N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21EM10

Product Code:

GSA/G-830-455-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

250mm

14/28

85mm

165mm

$78.95

GSA/G-250-165-1428

Buy Now

250mm

14/28

$78.95

GSA/G-250-165-1428

Buy Now

250mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

250mm

Diameter:

14/28

Stroke Length:

85mm

Compressed Length:

165mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21M10

Product Code:

GSA/G-250-165-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

600mm

14/28

260mm

340mm

$78.95

GSA/G-600-340-1428

Buy Now

600mm

14/28

$78.95

GSA/G-600-340-1428

Buy Now

600mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

600mm

Diameter:

14/28

Stroke Length:

260mm

Compressed Length:

340mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21M10

Product Code:

GSA/G-600-340-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

850mm

14/28

380mm

470mm

$89.95

GSA/G-850-470-1428

Buy Now

850mm

14/28

$89.95

GSA/G-850-470-1428

Buy Now

850mm Extended Length, 14/28 Diameter Gas Strut

$89.95

In Stock

Extended Length:

850mm

Diameter:

14/28

Stroke Length:

380mm

Compressed Length:

470mm

Force Range:

50-2000N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21EM10

Product Code:

GSA/G-850-470-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

295mm

14/28

105mm

190mm

$78.95

GSA/G-295-190-1428

Buy Now

295mm

14/28

$78.95

GSA/G-295-190-1428

Buy Now

295mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

295mm

Diameter:

14/28

Stroke Length:

105mm

Compressed Length:

190mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21M10

Product Code:

GSA/G-295-190-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

630mm

14/28

275mm

355mm

$78.95

GSA/G-630-355-1428

Buy Now

630mm

14/28

$78.95

GSA/G-630-355-1428

Buy Now

630mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

630mm

Diameter:

14/28

Stroke Length:

275mm

Compressed Length:

355mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21M10

Product Code:

GSA/G-630-355-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

885mm

14/28

400mm

485mm

$89.95

GSA/G-885-485-1428

Buy Now

885mm

14/28

$89.95

GSA/G-885-485-1428

Buy Now

885mm Extended Length, 14/28 Diameter Gas Strut

$89.95

In Stock

Extended Length:

885mm

Diameter:

14/28

Stroke Length:

400mm

Compressed Length:

485mm

Force Range:

50-2000N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21EM10

Product Code:

GSA/G-885-485-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

330mm

14/28

125mm

205mm

$78.95

GSA/G-330-205-1428

Buy Now

330mm

14/28

$78.95

GSA/G-330-205-1428

Buy Now

330mm Extended Length, 14/28 Diameter Gas Strut

$78.95

In Stock

Extended Length:

330mm

Diameter:

14/28

Stroke Length:

125mm

Compressed Length:

205mm

Force Range:

50-2200N

Thread:

M10X1.5

End Fitting:

GSA/F-BCM13-21M10

Product Code:

GSA/G-330-205-1428

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

505mm

16/32

182mm

323mm

$198.00

GSA/G-505-323-1632

Buy Now

505mm

16/32

$198.00

GSA/G-505-323-1632

Buy Now

505mm Extended Length, 16/32 Diameter Gas Strut

$198.00

In Stock

Extended Length:

505mm

Diameter:

16/32

Stroke Length:

182mm

Compressed Length:

323mm

Force Range:

100-3499N

Thread:

M10X1.5

End Fitting:

GSA/F-P-EF-B310-10

Force Increase over stroke:

40%

Stroke Dampened:

15%

Product Code:

GSA/G-505-323-1632

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

525mm

16/32

192mm

333mm

$198.00

GSA/G-525-333-1632

Buy Now

525mm

16/32

$198.00

GSA/G-525-333-1632

Buy Now

525mm Extended Length, 16/32 Diameter Gas Strut

$198.00

In Stock

Extended Length:

525mm

Diameter:

16/32

Stroke Length:

192mm

Compressed Length:

333mm

Force Range:

100-3500N

Thread:

M10X1.5

End Fitting:

GSA/F-P-EF-B310-10

Force Increase over stroke:

40%

Stroke Dampened:

15%

Product Code:

GSA/G-525-333-1632

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

580mm

16/32

220mm

360mm

$198.00

GSA/G-580-360-1632

Buy Now

580mm

16/32

$198.00

GSA/G-580-360-1632

Buy Now

580mm Extended Length, 16/32 Diameter Gas Strut

$198.00

In Stock

Extended Length:

580mm

Diameter:

16/32

Stroke Length:

220mm

Compressed Length:

360mm

Force Range:

100-3500N

Thread:

M10X1.5

End Fitting:

GSA/F-P-EF-B310-10

Force Increase over stroke:

40%

Stroke Dampened:

15%

Product Code:

GSA/G-580-360-1632

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

830mm

16/32

343mm

487mm

$212.70

GSA/G-830-487-1632

Buy Now

830mm

16/32

$212.70

GSA/G-830-487-1632

Buy Now

830mm Extended Length, 16/32 Diameter Gas Strut

$212.70

In Stock

Extended Length:

830mm

Diameter:

16/32

Stroke Length:

343mm

Compressed Length:

487mm

Force Range:

100-3500N

Thread:

M10X1.5

End Fitting:

GSA/F-P-EF-B310-10

Force Increase over stroke:

40%

Stroke Dampened:

15%

Product Code:

GSA/G-830-487-1632

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

1200mm

16/32

530mm

670mm

$235.20

GSA/G-1200-670-1632

Buy Now

1200mm

16/32

$235.20

GSA/G-1200-670-1632

Buy Now

1200mm Extended Length, 16/32 Diameter Gas Strut

$235.20

In Stock

Extended Length:

1200mm

Diameter:

16/32

Stroke Length:

530mm

Compressed Length:

670mm

Force Range:

100-3500N

Thread:

M10X1.5

End Fitting:

GSA/F-P-EF-B310-10

Force Increase over stroke:

40%

Stroke Dampened:

15%

Product Code:

GSA/G-1200-670-1632

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

1500mm

16/32

500mm

1000mm

$272.60

GSA/G-1500-1000-1632

Buy Now

1500mm

16/32

$272.60

GSA/G-1500-1000-1632

Buy Now

1500mm Extended Length, 16/32 Diameter Gas Strut

$272.60

In Stock

Extended Length:

1500mm

Diameter:

16/32

Stroke Length:

500mm

Compressed Length:

1000mm

Force Range:

100-3500N

Thread:

M10X1.5

Special Note:

Oversize - excluded from free shipping

End Fitting:

GSA/F-P-EF-B310-10

Force Increase over stroke:

21%

Stroke Dampened:

15%

Product Code:

GSA/G-1500-1000-1632

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

700mm

20/42

250mm

$361.89

GSA/G-700-366-2042-E8

Buy Now

700mm

20/42

$361.89

GSA/G-700-366-2042-E8

Buy Now

General Use Gas Strut 700mm Extended, 250mm Stroke, 20/42 Diameter, with EF-E8 eyes attached

$361.89

In Stock

Extended Length:

700mm

Diameter:

20/42

Stroke Length:

250mm

Force Range:

100-5200N

Thread:

M10X1.5

End Fitting:

EF-E8 eyes

Force Increase over stroke:

38%

Stroke Dampened:

15%

Product Code:

GSA/G-700-366-2042-E8

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

800mm

20/42

300mm

$374.23

GSA/G-800-416-2042-E8

Buy Now

800mm

20/42

$374.23

GSA/G-800-416-2042-E8

Buy Now

General Use Gas Strut 800mm Extended, 300mm Stroke, 20/42 Diameter, with EF-E8 eyes attached

$374.23

In Stock

Extended Length:

800mm

Diameter:

20/42

Stroke Length:

300mm

Force Range:

100-5200N

Thread:

M10X1.5

End Fitting:

EF-E8 eyes

Force Increase over stroke:

38%

Stroke Dampened:

15%

Product Code:

GSA/G-800-416-2042-E8

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

1200mm

20/42

500mm

$453.00

GSA/G-1200-616-2042-E8

Buy Now

1200mm

20/42

$453.00

GSA/G-1200-616-2042-E8

Buy Now

General Use Gas Strut 1200mm Extended, 500mm stroke, 20/42 Diameter, with EF-E8 eyes attached

$453.00

In Stock

Extended Length:

1200mm

Diameter:

20/42

Stroke Length:

500mm

Force Range:

100-5200N

Thread:

M10X1.5

End Fitting:

EF-E8 eyes

Force Increase over stroke:

38%

Stroke Dampened:

15%

Product Code:

GSA/G-1200-616-2042-E8

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

1202mm

20/42

500mm

$485.00

GSA/G-1202-590-2042-PHS14

Buy Now

1202mm

20/42

$485.00

GSA/G-1202-590-2042-PHS14

Buy Now

General Use Gas Strut 1202mm Extended, 500mm stroke, 20/42 Diameter, with EF-PHS14 eyes

$485.00

In Stock

Extended Length:

1202mm

Diameter:

20/42

Stroke Length:

500mm

Force Range:

100-5200N

Thread:

M10X1.5

End Fitting:

EF-PHS14 eyes

Force Increase over stroke:

38%

Stroke Dampened:

15%

Product Code:

GSA/G-1202-590-2042-PHS14

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

400mm

20/42

100mm

$330.60

GSA/G-400-216-2042-E8

Buy Now

400mm

20/42

$330.60

GSA/G-400-216-2042-E8

Buy Now

General Use Gas Strut 400mm Extended, 100mm Stroke, 20/42 Diameter, with EF-E8 eyes attached

$330.60

In Stock

Extended Length:

400mm

Diameter:

20/42

Stroke Length:

100mm

Force Range:

100-5200N

Thread:

M10X1.5

End Fitting:

EF-E8 Eyes

Force Increase over stroke:

38%

Stroke Dampened:

15%

Product Code:

GSA/G-400-216-2042-E8

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

500mm

20/42

150mm

$340.42

GSA/G-500-266-2042-E8

Buy Now

500mm

20/42

$340.42

GSA/G-500-266-2042-E8

Buy Now

General Use Gas Strut 500mm Extended, 150mm Stroke, 20/42 Diameter, with EF-E8 eyes attached

$340.42

In Stock

Extended Length:

500mm

Diameter:

20/42

Stroke Length:

150mm

Force Range:

100-5200N

Thread:

M10X1.5

End Fitting:

EF-E8 eyes

Force Increase over stroke:

38%

Stroke Dampened:

15%

Product Code:

GSA/G-500-266-2042-E8

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

600mm

20/42

200mm

$352.60

GSA/G-600-316-2042-E8

Buy Now

600mm

20/42

$352.60

GSA/G-600-316-2042-E8

Buy Now

General Use Gas Strut 600mm Extended, 200mm Stroke, 20/42 Diameter, with EF-E8 eyes attached

$352.60

In Stock

Extended Length:

600mm

Diameter:

20/42

Stroke Length:

200mm

Force Range:

100-5200N

Thread:

M10X1.5

End Fitting:

EF-E8 Eyes

Force Increase over stroke:

38%

Stroke Dampened:

15%

Product Code:

GSA/G-600-316-2042-E8

Measure Your Strut | Terms & Conditions | FAQ's | Warranty Guarantee |

1000mm

20/42

400mm

600mm

$431.00

GSA/G-1000-400-2042-E8

Buy Now

1000mm

20/42

$431.00

GSA/G-1000-400-2042-E8

Buy Now

General Gas Strut 1000mm Extended Length, 20/42 Diameter Complete with 14mm Eyelets End Fittings

$431.00

In Stock

Extended Length:

1000mm

Diameter:

20/42

Stroke Length:

400mm

Compressed Length:

600mm

Force Range:

'-5200N

Special Note:

Designed for versatile use across toolboxes, hatches, and panels. Heavy-duty 316 stainless construction. Usually ships within 2 days. 3-year warranty included.

End Fitting:

14mm Eyelets Thick M14 Thread in Base

Force Increase over stroke:

38%

Stroke Dampened:

15%

Product Code:

GSA/G-1000-400-2042-E8
